Product Details:
|
| Name: | Mixing-dryer | The Motor Power: | 7.5w |
|---|---|---|---|
| Speed: | 350r/min | Capacity: | 3000kgs |
| Highlight: | pet bottle crushing machine,plastic bottle crushing machine |
||
Specification of Cheapest Machine 3000 kgs Vertical Mixing Dryer For Plastic Particles
|
Model |
HH--500 |
HH--1000 |
HH--2000 |
HH--3000 |
HH--5000 |
|
Capacting(KG) |
500 |
1000 |
2000 |
3000 |
5000 |
|
The motor power(KW) |
3 |
4 |
5.5 |
7.5 |
11 |
|
Heating power(KW) |
12 |
20 |
30 |
40 |
50 |
|
Speed(r/min) |
350 |
||||
|
Overall dimensions(CM) |
120*120*235 |
160*160*265 |
175*175*355 |
220*220*385 |
240*240*435 |
We can design different plastic washing line according to your requirements:
Plastic mixing dryer advantages:
the hot air from the barrel at the bottom side of the traditional drying machine to enter, because raw material is static, so the hot air difficult
to penetrate, making dryer internal appear the phenomenon of lower heat the upper temperature, sometimes by local overheating of
sintering raw material, cause jams, to make it more difficult to enter other areas, hot air dry reason cannot reach the expected effect. The
design of the machine is two-stage screw slurry conveying, the first stage carries the raw materials into the barrel, the second stage lifts
the raw materials to the upper part of the barrel to scatter in an umbrella shape, and the hot air blows out from the center of the lower part
of the barrel to the four sides, so that the raw materials can be heated fully in the dynamic condition. Make plastic dryer series beautiful and
strong, temperature control, greatly improve the drying efficiency, complete machine types, there are general and dehumidification type,
widely won the trust and love of the plastic industry at home and abroad, is the modern plastic molding plant indispensable equipment.
