Product Details:
|
| Name: | Elegant Wire Fabric Laminated Glass | Whole Thickness: | 13mm |
|---|---|---|---|
| Glass Type: | White Tempered Glass | Film Type: | PVB |
| Interlayer Material: | Stainless Steel Wire Mesh, Brass Wire Mesh | Max Width: | 2500mm |
| PVB Th: | 0.38mm | Factory: | Huihao Hardware Mesh |
| Highlight: | Wire Fabric Laminated Glass,Elegant Wire laminated glass,Sliding Doors wire laminated glass |
||
The use of decorative glass in retail and commercial environments can be significantly enhanced via glass lamination. From glass wall coverings and millwork finish to structural glass partitions, lighting and stair treads - your choice of materials will be fused within glass for a complete design concept realization.
| name | over thickness | open area | weight |
| stainless steel wire fabric | 0.5mm | 48% | 1.1kgs/square meter |
| material | wire diameter | max width | hole type |
| stainless steel wire | 0.28mm | 3000mm | along pattern |
| Fire Resistance | Safety | Anti-theft Function |
| Even if the fabric laminated glass is broken, the wire or net can support the fragments, which are hard to collapse and break. fabric laminated glass can block the penetration of the flame and the fire powder when the flame is worn out and prevent the spread of the flame from the opening. According to the Japanese Building Standard Act Article 64, made the provisions of fire doors. The opening of the outer wall must prevent the flame from spreading and burning. Combined the wire glass with B kinds of fire doors frame, it can be used as a B fireproof material. |
transparent fabric laminated glass can prevent debris flying apart. Even in the face of earthquakes, windstorms, shocks and other external pressure break the glass, the fragments are very difficult to fly, so compared with ordinary glass, fabric laminated glass is much safety and not easy to cause debris scattered and wounding. | Ordinary glass is very easy to break, so thieves can sneak into illegal activities, while the fabric laminated glass is not. Even if the glass is broken, there is still metal wire mesh at work, so the thief can not easily steal. This anti-theft glass wire clip gives people a sense of security psychologically. |
| Elegant Wire Fabric Laminated Glass materials include: | copper wire weave mesh, copper rope mesh, copper laser cutting mesh |
| glass type |
|
| Whole thickness of Elegant Wire Fabric Laminated Glass |
|
| Whole size of Elegant Wire Fabric Laminated Glass |
|
|
|
|
Elegant Wire Fabric Laminated Glass is formed as a sandwich of 2 sheets of glass which are bonded together with PVB interlayer under heat and pressure. It could be two pieces of clear float glass bonded with color PVB, also could be color float glass bonded with clear PVB, the performance almost the same, but the color PVB is cheaper than color float glass, so prefer which type, depends on your requirement. |
Elegant Wire Fabric Laminated Glass is Widely used in this modern world such as :
1. Glass partition wall 2. Glass window 3. Shower enclosure 4. bathroom door 5. Sliding doors
