Product Details:
|
| Product Name: | Solar Panel Mesh Aluminum Clips | Application: | Fasten The Solar Panel Mesh |
|---|---|---|---|
| J Clip Size: | 2.4mmx95mm | Washer Size: | 29mmx31mm |
| Contain: | Self Locking Washer And Hook | Manufacturer: | Yes |
| OEM ,ODM: | Support | Packing: | 500 Or1000pcs In One Plastic Bag |
| Highlight: | uv resistant solar panel clips,phosphating polish solar panel clips,phosphating polish solar panel mesh clips |
||
UV resistant Solar Panel Exclusion Squirrels Guard Mesh protection aluminum clips
Solar Panel Bird/Critter Guard Clips are designed to fasten the critter guard mesh to solar panels without
any intrusions or damage. The clips and the mesh used together prevents birds from nesting under solar
arrays and other critters from entering and damaging the system. This item should be able to be installed
on almost any solar system and is weather is UV resistant.
| Material |
aluminum and aluminum alloy |
Stainless steel |
| J hook size in common: | 2.5mmx95mm | 2.5mmx95mm |
| Surface treatment | phosphating | Polish |
| Solar panel clips including | J hook nails and self locking washers | |
| Self locking washer size: | 29mmx31mm, 30mmx30mm, 30mmx60mm | |
|
Calculating the necessary number of clips: Use 2 clips for the short side of every exposed edge of a panel and 3 clips for the long side of every exposed edge of a panel. |
||
QTY needed for installation:
. The number of clips needed will depend on the solar panel system.
· Calculating the necessary number of clips: Use 2 clips for the short side of every exposed edge of a panel
and 3 clips for the long side of every exposed edge of a panel.
Slide the speed washer onto the shaft of the clip assembly until snug.Tighten speed washer to panel edge
to immobilize the mesh ,cut of the clip assembly rod flush with the exterior of the speed washer by cutter
| features of Solar Panel Bird Deterrent Aluminum J Hook Clips |
|
· No need to drill or damage the panels |
|
J Hooks Package |
Self Locking Washer Package |
|
1. 100 pcs per pp bag, 80 bags per carton 2. 500pcs per pp bag, 16bags per carton 3.1000pcs per pp bag, 8 bags per carton Carton size: 41 cm x 28 cm x17 cm
|
1.100 pcs per pp bag, 60 bags per carton 2. 500pcs per pp bag, 12bags per carton 3.1000pcs per pp bag, 6 bags per carton Carton size: 41 cm x 28 cm x17 cm
|
|
The J hooks & washers usually pack with plastic bags +cartons. |
|
