Product Details:
|
| Product Name: | Metal Safety Anti Skid Stair Treads | Fasteners: | BOLT SEATS,MID-CLIP,J-CLIP |
|---|---|---|---|
| Length: | 120" And 144" Lengths (nominal) | Width: | 9" 10" (nominal) |
| Thickness: | 3mm-5mm | Heigh: | 50mm ,80mm Or To Request |
| Highlight: | aluminum safety grating,aluminum plank grating |
||
Safety Anti Skid Stair Treads details
________________________________________________________
Metal Safety Anti Skid Stair Treads of round hole skid plates has a wide range of uses. Many large-scale oil production
and miners are highly dependent on round-hole skid plates. The round hole anti-skid plate products produced by Huijin
anti-skid board manufacturers mainly use different materials such as low carbon steel, stainless steel plate, aluminum
plate and aluminum alloy. The thickness of the conventional skid plate is mainly in the range of 1.5mm-4.0mm. Of course,
if it is a special specification, we will customize it according to the customer's requirements.
The design of the circular hole anti-skid plate has a combination of a large hole and a small hole, and the design of the
hole type has a flanged protrusion and a normal punching. Therefore, it is determined that the use of the circular hole
skid plate can not only prevent slipping, but also can cause water leakage and oil leakage for the normal hole..
Metal Safety Anti Skid Stair Treads specification
____________________________________________________________
| Metal Safety Anti Skid Stair Treads | ||||||||||
| Material | steel | Aluminum | Stainless | |||||||
| Gauge | 13Ga, | 11Ga | 0.125 | 16Ga | ||||||
| Channel Depth | 1-1/2", 2", 3" | 1-1/2", 2", 3" | 1-1/2", 2" | 2" | ||||||
| Length | 120" and 144" lengths (nominal) | |||||||||
| Width | 7" | 10" | 12" | 7" | 10" | 12" | 7" | 10" | 12" | |
| Hole number | 9 | 14 | 19 | 9 | 14 | 19 | 9 | 14 | 19 | |
| Hole Diameter | 3/8" | |||||||||
| Hole Size | 0.10" | |||||||||
| Button Height | 0.14" | |||||||||
| Metal Safety Anti Skid Stair Treads with large hole | ||||
| Material | Steel | Aluminum | Stainless | |
| Gauge | 13Ga, | 11Ga | 0.125 | 16Ga |
| Channel Depth | 1-1/2", 2", | 1-1/2", 2", | 1-1/2", 2", | 2" |
| Length | 120" and 144" lengths (nominal) | |||
| Width | 9" 10" (nominal) | |||
| Hole number | 6 | |||
| Hole diameter | 1/2" | |||
| Hole size | 0.155" | |||
| Button height | 0.213" | |||
images of Safety Anti Skid Stair Treads
__________________________________________________________________
Metal Safety Anti Skid Stair Treads Application:
_____________________________________________________________________________________
Metal Safety Anti Skid Stair Treads Widely used in petroleum, chemical, mining, electric power, marine exploration, electro plating,
shipbuilding, water and wastewater treatment, papermaking, brewing, pharmaceutical and other industries, work platforms,
equipment platforms, stair treads, trench cover, bridge walkways, filter plates, Filler brackets, etc., are ideal load-bearing materials
in corrosive environments.
