Product Details:
|
| Name: | Rock Wool Fixed Insulation Nail | Type: | Self Adhesive Pin |
|---|---|---|---|
| Nail Length: | 25 Mm -280 Mm | Nail Dia: | 12 GA |
| Base Size: | 2 Inches Square Type | Material: | Galvanized Steel |
| Base Th: | 1mm | Factory: | Huihao Hardware |
| Highlight: | self stick nails for insulation,rock wool fixed nails for insulation,self adhesive nails for insulation |
||
1. Pin Length: 38mm - 230mm in standard, others can be customized
2. Galvanised steel with self-adhesive base 50 x 50 mm (2" x 2") of acrylic coated white closed cell polyethylene foam backing ( plain and reinforced backing are both available )
3. Zinc plated or copper plating finished for steel pins, the steel wire is must be anneaded before finished.
4. Fastening clips with Bevelled edges and standard outside diameter 30mm ( 1-3/16" ) in standard
| Self Adhesive type - rock wool fixed insulation nails | |
| Common specifications | Length: 1-1/4” - 8” |
| Diameter:12GA ,14GA | |
| Base : 2” * 2” | |
| Material | Pin: Stainless steel, Aluminum, Stainless steel |
| Base: High strength galvanzied steel, stainless steel ,Aluminum | |
| Surface treatment | Polishing, galvanzied plating |
| Product features | Firm conjunction between pins and bases |
| Pins are soft, easy bending over | |
| Excellent stickness for double-sided adhesive property | |
| Length tolerance ±0.1mm | |
| Production workmanship | Automated production |
| Packing |
Packing can be customized as per requirements, current packing information available upon request. |
| Supply capability | 10000Pcs/hour |
| Application |
During construction, The bottom plate is glued to the surface of the air tube, and then the rock cotton plate is fixed after the glue is cured. The top is stuck with a self locking washer to the rock cotton plane, press according to the thickness of the rock cotton plate, and then bend the nail hook
|
| Remark | Technical parameters are available upon request |
