2.5" Self Adhesive Insulation Fastener Pins For Fiberglass Duct Wrap On Sheet Metal

Name: 2.5" Self Adhesive Insulation Fastener Pins For Fiberglass Duct Wrap On Sheet Metal
Brand: Huihao Hardware Mesh Product Limited
SKU: Self Adhesive Insulation Fastener Pins
Price: Negotiable USD
Availability: InStock

All Products

Self Adhesive Insulation Pins
(115)

Insulation Anchor Pins
(155)

Metal Mesh Drapery
(114)

Architectural Wire Mesh
(113)

Tile Backer Board Washers
(54)

Fabric Laminated Glass
(50)

Metal Ring Mesh
(98)

Solar Panel Clips
(71)

Grip Strut Grating
(32)

Self Locking Washer
(112)

Expanded Metal Mesh
(40)

Metal Coil Drapery
(32)

Decorative Wire Mesh
(99)

Self Cleaning Screen Mesh
(89)

Stud Welding Pins
(185)

Johnson Wire Screen
(38)

Plastic Recycling Line
(37)

Ultra Fine Wire
(15)

Stainless Steel Wire Rope Mesh
(15)

Best Products

50mm Base Metal Self Adhesive Insulation Pins Adhesive Insulation On Smooth Surface

Certification

Customer Reviews

Great! Place next order in near future

—— Joe Paletta

Many thanks for your service and the coil mesh is so beautiful.

—— Mélissa Tovar

Recieved the insulation pins, Everything looks good.

—— Ivan

Zhijing.Gao is a great associate to do business with. she is honest and clear with communication. I will do business with them again

—— Amila

I ordered a custom mesh metal chain curtain for my charity dinner event in Canada for CANFAR. I was a bit crammed on timing and Cherry managed to get it to me on time. I had to pay a bit more for express shipping but it was worth the cost. I am happy. thank you!!!

—— Daerye

Emily introduce the Perforated base pin clear and helpful to me. Good service and good guality.

—— Karl

I'm Online Chat Now

2.5" Self Adhesive Insulation Fastener Pins For Fiberglass Duct Wrap On Sheet Metal

Large Image : 2.5" Self Adhesive Insulation Fastener Pins For Fiberglass Duct Wrap On Sheet Metal

Product Details:

Place of Origin:	China
Brand Name:	HUIHAO
Certification:	ISO9001-2015
Model Number:	Self Adhesive Insulation Fastener Pins

Payment & Shipping Terms:

Minimum Order Quantity:	10000 pcs
Packaging Details:	500pcs per carton, 48 cartons per pallet,
Delivery Time:	10 work days
Payment Terms:	L/C, T/T,
Supply Ability:	10000 pcs oer hour

Contact Now

2.5" Self Adhesive Insulation Fastener Pins For Fiberglass Duct Wrap On Sheet Metal

Description

Name:	Self Adhesive Insulation Fastener Pins	Brand:	Huihao Custom
Material:	Galvanized Steel Or Stainless Steel	Base Size:	50x50mm
Product Customization:	Support	Pin Diameter:	2.7mm As Standard
Samples:	Support	Pin Length:	38mm-230mm In Standard
Highlight:	2.5" self stick insulation pins , stainless steel self stick insulation pins , 2.5" insulation pins self adhesive

2.5" Self Adhesive Insulation Fastener Pins For Fiberglass Duct Wrap On Sheet Metal

Quick Details Of The 2.5" Self Adhesive Insulation Fastener Pins:

Self Adhesive Insulation Fastener Pins are popular due to their fast and quick install.
Simply remove the release paper and stick the pin onto the sheet metal.
Make sure to apply a firm and even pressure onto the base to insure a proper bond.

Brand	HUIHAO CUSTOM
Name	2.5" Self Adhesive Insulation Fastener Pins
Material	Galvanized Steel
Base size	50x50mm
Pin diameter	2.7mm
Pin length	2 1/2” / 63.5mm

Specifications Of The Self Adhesive Insulation Fastener Pins:

Product Name	Self Adhesive Insulation Fastener Pins
Material	Stainless Steel GI - Galvanized Steel Aluminium
Base Size	50x50mm, 40x40mm etc.
Pin Diameter	12ga, 3mm etc.
Pin Length	3/4" - 10" (19mm-250mm)
Features	Firm conjunction between bases and pins Pins are soft, easy bending over Porous base designed for permeating glue easily Length tolerance ±0.1mm
Advantages	1. The pins are riveted on the base of the self adhesive insulation fastener pins, it's very strong. 2. The self adhesive tape on the base botom of the self adhesive insulation fastener pins is very sticky. 3. The self locking washers are very hard, it could lock the self adhesive insulation fastener pins very firmly.

Application Of The Self Adhesive Insulation Fastener Pins:

1. Self adhesive insulation fastener pins can only be stuck on clean, dry and smooth surface.

2. Cleaning the surface is recommended, remove any duct, loose paint, oil etc.
3. Peel off the backing paper.
4. Place the self adhesive insulation fastener pins in the required position.

5. Press the base against the cleaning surface.

6. Impale the insulation over the point of the self adhesive insulation fastener pins.

7. Secure the insulation with the self locking washers.

8. Bend or remove excess pins

Package Details Of The Self Adhesive Insulation Fastener Pins:

PIN LENGTH	CARTON SIZE	QTY/CARTON
38MM	41CMX28CMX17CM	1000PCS
50MM-65MM	41CMX28CMX17CM	500PCS
70MM-84MM	30CMX28CMX29CM	500PCS
90MM-120MM	30CMX30CMX30CM	500PCS
130MM-160MM	30CMX30CMX35CM	500PCS
170MM-203MM	30CMX30CMX28CM	250PCS
OTHERS	SUPPORT CUSTOM	SUPPORT CUSTOM

Huihao Hardware Mesh Product Limited.

1. We choose the best quality materials for making insulation fasteners
2. We do copper plating, zinc coated and phosphating pretreatment for the raw material
3. We purchase the multi-station cold forging machine to ensure the better mechanical property of shear connector to match the standard (BS EN ISO13918:2008, AWS D1.1, etc.), or as per customer's special requirement.
4. We use the automatic riveting machine to install .
5. After rust prevention, HUIHAO insulation fasteners can suitable for long time ship on the sea.
6. Short delivery time because of our reasonable production flow management.
